Using Visualisers with VLC Player

Introduction

This guide provides step-by-step instructions to help you connect and use a visualiser (document camera) with VLC Media Player. This setup allows you to display physical documents or objects on your computer screen, facilitating presentations and classroom activities.

Step-by-Step Instructions

Step 1: Open VLC Media Player

• Launch the VLC Media Player application on your computer.

Step 2: Access the Capture Device Settings

• Click on the Media menu located at the top-left corner of the VLC window.

• From the dropdown menu, select Open Capture Device.

Step 3: Configure Video and Audio Settings

• In the Open Media dialog box that appears:

  • Video Device Name:

    • Click on the dropdown menu under Video device name.

    • Select AverVision U50 (or the name corresponding to your visualiser model).

  • Audio Device Name:

    • Click on the dropdown menu under Audio device name.

    • Select None if you do not require audio input from the visualiser.

Step 4: Start the Playback

• After configuring the settings, click the Play button at the bottom of the dialog box.

• VLC Media Player will now display the live feed from the visualiser on your screen.

Troubleshooting Tips

• No Video Display:

  • Ensure that the visualiser is properly connected to your computer.

  • Verify that the correct video device name is selected in VLC's settings.

• Poor Video Quality:

  • Check the lighting conditions and adjust the focus on the visualiser.

  • Ensure that your computer meets the necessary hardware requirements to process the video feed.

Additional Resources

• Visualizer Usage Instructions

• VLC Media Player Documentation

FAQs

Q: Can I record the visualiser's output using VLC Media Player?

A: Yes, VLC Media Player allows you to record the input from the visualiser. To do this, navigate to the View menu and select Advanced Controls. This will display additional buttons, including a record button, which you can use to start and stop recording.

Q: Is it possible to adjust the resolution of the visualiser's output in VLC?

A: Yes, you can adjust the resolution by going to Tools > Preferences > Input / Codecs and modifying the settings under Capture Device. Ensure that the selected resolution is supported by both your visualiser and computer.
